Đầu cảm biến khói quang

Liên hệ

Characteristics:



- The standard detector is 2-wire or 3-wire. For 4-wire type just add one relay output module on 3-wire base. Simple and easy module placement enables wider application and flexible stock control.

- Detector is made of high endurance, solid and colorfast Fire-proof plastic.

- Non-loosening screws on base terminal for easy installation.

- Detector has passed strict EMC test, which greatly eliminates false alarms caused by interference from nearby sources.

- Dual LEDs for 360-degree visibility. Bi-color LED, Stand-by Status: Green; Alarm Status: Red.



Specifications

Model

Q01-2

Q01-3

Q01-4

Alarm Contact

N/A

N/A

0.8A @30V DC
0.4A @125V AC

Voltage Range

12 ~ 30V DC

Alarm Current
@24V DC 470Ω

40mA

40mA

45mA

Standby Current
@24V DC 470Ω

Under 75μA

Sensitivity Setting

Comply to EN54

Ambient Temperature

-10oC ~ +55oC

Material

Fire-proof plastic

Dimensions (mm) Dia. x H

102 x 48

Weight

130g

130g

145g

Color

White
