Đầu cảm biến khí gas

Giá 360.000₫

Characteristics:

- The AH-0822 features advanced technology, high accurate detection, low power-consumption and fast reaction time. It can detect natural gas and propane gas. Built-in buzzer and LED indicator alert by sounding and flashing.

- Sounding and flashing in alarm status; the green LED is lit during monitoring and the red LED flashes in alarm status.

- Dual power input: 12VDC and 24VDC operation in the same unit. No adjustment is required.

- Optional 110VAC or 220VAC adaptor is available.


Specifications:

Model

AH-0822

Approval

UL

CE

Power Source

24V DC

12V DC

24V DC

12V DC

Standby Current

25~30mA

40~45mA

35~40mA

65~70mA

Alarm Current

40~70mA

50~75mA

75~90mA

90~105mA

Warm-up Period

5 ~ 8 minutes

About 35 seconds

Warm-up Period

5 ~ 8 minutes

About 35 seconds

Sensitivity

0.021 ~ 0.300% (Propane)
0.050 ~ 0.714% (Methane)

0.05 ~ 0.30%

Alarm Sound

85dB/3M and above

90dB/M and above

Detection Type

Natural Gas & Propane Gas

Ambient Temperature

-10oC ~ +55oC

Dimensions (mm)
Dia. x H

102 x 40.5

Weight

Aboaut 130g
