Trung Tâm báo cháy HoringLih 8 Zone
Liên hệ
Characteristics
Model range from 1 to 32 zones.
AC power supply has EMI (Electromagnetic Interference).
Each zone has a separate disable function.
Double sets of sounder contacts.
Automatic telephone dialer feature.
Long-term or temporary silencing feature.
Protection against voltage spikes up to 2.5KV.
Microprocessor-base design.
Sounder short circuit or disconnection detection.
Fire Alarm NO, NC, COM and Fault NO, NC, COM output contact points.
Fire Relay Output contacts and Fault Relay Output contacts.
Switch membrane provides longer service and is waterproof, dust resistant and easy to clean.
Specifications
|
Zone |
32 zones |
8 zones |
4 zones |
|
Model |
AH-03312-32L |
AH-03312-8L |
AH-03312-4L |
|
Power Source |
220V AC/50Hz |
||
|
Battery Capacity |
24V / 12Ah |
24V / 7Ah |
24V / 4Ah |
|
Max. Output Current |
2A @24V DC |
||
|
# of heat detector connected |
No limit *Except electronic-type |
||
|
# of smoke detector connected |
30/zone *Horing Lih manufactured |
||
|
Max. No. of Bells @25mA |
40 per sounder circuit |
||
|
End of Line Resistor |
4.7kΩ *One per zone |
||
|
Material |
1.2mm steel plate |
||
|
Color |
Pearl gray *Others also available |
||
|
Dimensions (mm) H x W x D |
550 x 400 x 150 |
370 x 340 x 135 |
320 x 250 x 100 |
|
Optional Features |
LCD display (2x20) with simple function keypad |
N/A |
|
